What is Safety Marking Tape Photoluminescent?
Safety Marking Tape Photoluminescent is a glow-in-the-dark safety tape designed to outline hazards, emergency exits, and safety equipment in low-light conditions. What sets this tape apart is its combination of photoluminescent material and contrasting black sections, allowing for clear visual contouring of objects and areas. This dual-color design helps mark the outlines of doors, obstacles, clear zones, or life-saving equipment such as fire extinguishers, even during power outages or emergencies.
How to use Safety Marking Tape Photoluminescent
To ensure maximum performance and visibility, apply the tape using the following steps:
1. Surface preparation: Clean and dry the surface where the tape will be applied. Remove all dust, oil, or debris to ensure strong and lasting adhesion.
2. Application: Unroll the tape and press it firmly onto the desired surface, ensuring that the black and photoluminescent sections are oriented correctly for the intended marking. Smooth out any air bubbles and follow the contours of the object or area being outlined.
3. Charging the photoluminescent layer: Allow the tape to absorb light (natural or artificial) to activate the glow-in-the-dark feature. Ensure that installation areas receive enough lighting to keep the material fully charged.
4. Inspection: Periodically check the tape for wear, especially in high-traffic areas. Replace if the visibility or glow effect fades over time.
Where to use Safety Marking Tape Photoluminescent
Manufactured with a durable PVC or PET base and backed by an adhesive layer, Safety Marking Tape Photoluminescent adheres securely to a wide range of surfaces. It is used aboard ships to clearly mark the contours of emergency exits, stairways, door frames, protruding objects, and areas that must be kept clear during an evacuation. It is particularly useful in engine rooms, hallways, and muster stations where visibility can be compromised during emergencies.
In addition to maritime applications, Safety Marking Tape Photoluminescent is also ideal for buildings, warehouses, factories, and other facilities where safety marking is critical in low-light environments. Its durability and glow performance make it a reliable choice for both permanent and temporary installations.
Quality
LightLine Photoluminescent Tape comes in two different qualities, Class XXL and Class M. The difference between Class XXL and Class M lies mainly in their luminance performance. Class XXL provides a luminance intensity of 200 mcd/m² after 10 minutes and 30 mcd/m² after 60 minutes. Class M reaches 50 mcd/m² and 7 mcd/m² after the same periods.
The material of our Photoluminescent Tape is designed for both strength and durability. It has an elongation of 24%, which gives it a certain flexibility without compromising stability. With a thickness of 0.175 mm, it remains lightweight yet robust enough for demanding environments. The tensile strength is approximately 5 kg, ensuring reliable performance under tension. Depending on the size, the material weighs 300 g for 40 mm, 375 g for 50 mm, and 600 g for 80 mm, making it suitable for a wide range of applications.
Standards & Approvals
Safety Marking Tape Photoluminescent complies with all relevant international safety standards, including:
- IMO A.752(18) – Guideline for low location lighting systems on passenger ships
- ISO 15370 – Ships and marine technology: low location lighting systems
- Fully compliant with SOLAS regulations
These certifications confirm its suitability for professional marine and industrial use, supporting regulatory compliance and enhanced safety.
For Safety Marking Tape (Photoluminescent) without stripes, check our regular Photoluminescent Tape here.
